A project requires a clash-free 3D model and fabrication package for DN250 traditional mild-steel pipes in the UK. The design includes insulation, flange specifications, maximum span details, and compliance with BS EN standards.

The scope of work includes building pipework geometry, detailing supports, producing fabrication drawings, and supplying native files. Acceptance criteria ensure no clashes, proper support dimensions, and complete drawing sets for fabrication.
